Ibanez TOD70 Tim Henson Signature 7-String – Classic Silver w/Bag

Ibanez TOD70 Tim Henson Signature 7-String – Classic Silver w/Bag

$1,699.99

Ibanez TOD70 Tim Henson Signature 7-String – Classic Silver w/Bag

Description

Ibanez TOD70 Tim Henson Signature 7-String – Classic Silver w/Bag

Brand New Ibanez Tim Henson 7-String

SPECS

neck type AZ7 Oval CRoasted Maple neck

top/back/body American Basswood body

fretboard Ebony fretboardTree of Death inlay

fret Jumbo Stainless Steel frets

number of frets 24

bridge Gotoh® T1572S tremolo bridge

string space 10.5mm

neck pickup Fishman® Fluence™ Tim Henson Signature Series 7 (H) neck pickupActive/Alnico

bridge pickup Fishman® Fluence™ Tim Henson Signature Series 7 (H) bridge pickupActive/Alnico

factory tuning 1E,2B,3G,4D,5A,6E,7B

strings D’Addario® EXL110-7

string gauge .010/.013/.017/.026/.036/.046/.059

nut Graph Tech®

hardware color Chrome

NECK DIMENSIONS

Scale : 648mm/25.5″

a : Width 47mm at NUT

b : Width 66mm at 24F

c : Thickness 20.5mm at 1F

d : Thickness 22.5mm at 12F

Radius : 305mmR

DESCRIPTION

SWITCHING SYSTEM

TOD70’s Switching system diagram

DESCRIPTION

CONTROLS

TOD70’s control diagram

DESCRIPTION

OTHER FEATURES

Recommended Case MR500C

Fishman® Fluence™ Voicing switch on tone control (push/pull) for Tim Henson Signature Series pickups

Gotoh® MG-T locking machine heads

Luminescent side dot inlay

Gig bag included

Features

Oval C Roasted Maple neck

Oval C Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.

Ebony fretboard

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

Jumbo Stainless Steel frets

Jumbo Stainless Steel frets

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response and effortless articulation when playing chords and clear tone when playing single notes.

American Basswood body

American Basswood body

The American Basswood body delivers a natural and flat tone.

Fishman® Fluence™ Tim Henson Signature Series 7 Humbacker pickups

Fishman® Fluence™ Tim Henson Signature Series 7 Humbacker pickups

Tim’s signature Fishman® Fluence™ pickups span the entire range of aggressive lead and rhythm tones to the cleanest of clean single coil combinations, even touching on sounds Tim was previously only able to produce with his acoustic guitars.Neck Pickup Voice 1: Thick and smooth neck humbucker / Voice 2: Hyper-clean, nylon string surrogate/ Voice 3: Tim’s fluid neck single coilBridge Pickup Voice 1: Based on Fishman®’s hot-rodded Classic voice, the quintessential lead tone of generation / Voice 2: Combination of Tim’s favorite bridge humbuckers / Voice 3: Tim’s ideal single coil combination tone when used in conjunction with neck coil

Gotoh® MG-T locking machine heads

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Gotoh® T1572S tremolo

Gotoh® T1572S tremolo

The T1572S tremolo bridge features steel saddles and a steel tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.

Fishman® Fluence™ Voicing switch on tone control (push/pull) for Tim Henson Signature Series pickups

Fishman® Fluence™ Voicing switch on tone control (push/pull) for Tim Henson Signature Series pickups

The Voicing switch allows the pickups to switch between three musically complementary voices.

Luminescent side dot inlays

Luminescent side dot inlays

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
